Force Testing Equipment and Force Tester Calibration

EasyGates Direct are an official Training Center and distributor of GTE's range of gate & door force testing equipment. Made in Germany, these high quality force testers offer the installer a robust solution for all of their force testing needs. The GTE range provides three distinct solutions to installers & manufacturers, available in protective carry cases with (optional) extension arm sets.

KMG LITE
The KMG LITE tester provides a highly affordable solution to installers who require maximum performance & versatility from their testing equipment whilst also keeping costs down. The LITE unit carries no on-board memory or PC connectivity, allowing the user to record the results manually without the need for connection to a PC or laptop. The website www.forcetesttool.co.uk can be used to easily create comprehensive reports with manually recorded data.

Features:
  • Standalone One-Hand Gauge
  • Illuminated numeric display
  • Mechanical Overload Protection
  • Voltage supply with standard AA-batteries
KMG LITE-BT
The KMG LITE Bluetooth tester builds on the ease of use and flexibility of the standard LITE tester, whilst adding the benefit of connectivity to a smartphone or tablet. The KMG APP holds all the tools a busy installer requires to produce accurate test reports on-site. With pre-setup templates for the industry recognised DHF TS code of practice documents, the APP can create full reports that can be saved to the device or e-mailed directly to the office or client.

Features:
  • Standalone One-Hand Gauge
  • Illuminated numeric display
  • Bluetooth connectivity on-board
  • iOS & Android app for smartphones & tablets
  • Mechanical Overload Protection
  • Voltage supply with standard AA-batteries

Click diagrams to enlarge

KMG-2000

The KMG 2000 tester is the flagship solution for installers who require great flexibility and features combined with huge measurement storage capacity. The KMG-2000 unit carries on-board memory facilities for 500 measurements (166 sets or approx. 18 gates) and provides USB PC connectivity. This allows the user to record the results from many gate tests, then using the software package produce comprehensive reports detailing the full extent of the force test data.

Features:
  • Large memory capacity - 500 Tests
  • Full software package for professional report creation
  • Solid stainless steel construction
  • UK calibration available
Spec:
  • Fully compliant with EN 12453/12445, EN 16005 & DHF TS code of pratice
  • Illuminated LCD-Display
  • Graphical display of measurement values and limits
  • Mechanical overload protection
  • Rechargeable (approx. 100 hrs of operation without charging)
  • Automatic averaging
  • Automatic start of measurement possible
  • USB interface for data transfer
  • Fixation attachments in various inclinations available
Force Tester Calibration
Force tester calibration

EasyGates Direct have been appointed as a UK calibration centre for the GTE range of force testing equipment.

Quick, reliable UK Calibration service for the busy installer who can't be without their equipment for weeks!

This recalibration service includes a certificate and takes 1 - 2 working days to be completed.

We are currently offering recalibration at,

  • £110 + VAT (KMG LITE /LITE-BT Only)
  • £175 + VAT (KMG-2000 G Units Only)
  • £250 + VAT (KMG-2000 "L" Units , or "G" units requiring factory update/calibration)

Contact us now to book your calibration!

ASO Safety Edge Systems
ASO's SENTIR edge safety contact edges are a range of pressure sensitive sensors which guard closing edges at crushing and shearing points where there is a risk of injury. ASO's safety edges are suitable for automatic gates and doors, machinery and handling equipment, and numerous other applications.

See our ASO Safety Edges section for more info
Show:
Sort By:

GTE KMG 2000-G Force Tester

The GTE KMG 2000-G force tester is the flagship solution for installers who require great flexibility and features combined with huge m..

GTE KMG-LITE-BT Force Tester With Bluetooth Module

The GTE KMG LITE-BT bluetooth force tester provides a cost effective solution to installers who need top performance & gr..

GTE KMG-Lite Spacer Set

An additional accessory for KMG-Lite & KMG-Lite Bluetooth we offer is the spacer set, which contains a robust measurement tripod and dis..

GTE KMA 2000 Spacer Kit 300mm / 500mm For KMG-2000-G

This optional accessory for the KMG-2000 force tester is a robust metal spacer kit, of which contains high-quality distance pieces for typic..

GTE KMG VD 2005 Evaluation Software

The GTE KMG-VD is a vital piece of archiving and evaluation software that is an essential accessory specially developed for GTE's KMG-2..

GTE KMG Extension Set

The KMG Extension Set provides additional screw-on extension pieces for the existing KMG Spacer Set. These are for use with the popular KMG-..

GTE KMG-Lite Force Tester

The GTE KMG LITE force tester provides a highly affordable solution to installers who require maximum performance & versatility from the..
