The TP-Link TL-SG1218MP is an 18-port Gigabit rackmount PoE+ switch designed for business networks, CCTV systems, offices and other installations requiring reliable Power over Ethernet. It features 16 Gigabit PoE+ ports, 2 non-PoE Gigabit ports and 2 combo Gigabit SFP slots for flexible network connectivity.
With a 250 W total PoE power budget and up to 30 W per PoE port, the TL-SG1218MP can power IP cameras, wireless access points, IP phones and other compatible PoE devices. Its plug-and-play design requires no configuration, while QoS and intelligent power management help maintain reliable network performance.
Key Features
- 16 x gigabit PoE+ RJ45 ports, 2 x gigabit non-PoE RJ45 ports, and 2 x combo gigabit SFP slots
- High PoE power budget with up to 30 W for each PoE port and 250 W for all PoE ports
- Working with IEEE 802.3af/at compliant PDs
- Plug and play, with no configuration and installation needed
- 802.1p/DSCP QoS enable smooth latency-sensitive traffic
- Durable metal casing and professional heat dissipation design ensure a wide operating temperature range (0 - 50°C)
Kit Contents
- 1 x TP-Link TL-SG1218MP Switch
- 1 x Power Cord
- 1 x Installation Guide
- 1 x Rackmount Kit
- 4 x Rubber Feet
Manuals & dDatasheets
Technical
| HARDWARE FEATURES | |
|---|---|
| Standards & Protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p |
| Interface | 16 x PoE+ gigabit RJ45 ports 2 x gigabit non-PoE RJ45 ports 2 x combo gigabit SFP slots |
| Network Media |
|
| Fan Quantity | 2 |
| Physical Security Lock | Yes |
| Power Supply | 100 - 240 VAC, 50/60 Hz |
| PoE Ports (RJ45) | Standard: 802.3at/802.3af compliant PoE Ports: Ports 1 - 16 PoE Power Budget: 250W |
| Dimensions (W x D x H) | 17.3 x 7.1 x 1.73in (440 x 180 x 44mm) |
| Mounting | Rack Mountable |
| Max. Power Consumption | 21.4 W (220/50 Hz. no PD connected) 286.64 W (220/50 Hz. with 250 W PD connected) |
| Max. Heat Dissipation | 72.97 BTU/h (no PD connected) 977.44 BTU/h (with 250 W PD connected) |
| PERFORMANCE | |
| Switching Capacity | 36Gbps |
| Packet Forwarding Rate | 26.78Mbps |
| MAC Address Table | 8K |
| Packet Buffer Memory | 4.1Mbit |
| Advanced Features |
|
| Jumbo Frame | 10KB |
| OTHER | |
| Certification | FCC, CE, RoHS |
| Package Content |
|
| Environment | Operating Temperature: 0°C ~ 50°C (32°F ~ 122°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) Operating Humidity: 10% ~ 90% RH non-condensing Storage Humidity: 5% ~ 90% RH non-condensing |
