The TP-Link TL-SG1210P is a versatile Gigabit PoE+ switch designed to provide reliable network connectivity and power delivery for surveillance, wireless networking, and VoIP deployments. Featuring 9 Gigabit RJ45 ports and 1 Gigabit SFP uplink port, it offers flexible connectivity for growing business and home networks. With 8 PoE+ ports, the TL-SG1210P can transmit both power and data over a single Ethernet cable, making it ideal for IP cameras, wireless access points, and IP phones. The switch supports IEEE 802.3af/at-compliant devices, providing up to 30W per PoE port and a total 63W PoE power budget for connected equipment.
Designed for simple deployment, the TL-SG1210P offers plug-and-play operation with no configuration required. Advanced features such as QoS traffic prioritisation help ensure smooth performance for voice and video applications, while IGMP Snooping optimises multicast traffic for IPTV and multimedia streaming. The switch is housed in a durable metal enclosure with desktop and wall-mounting options to suit a variety of installation environments. A fan-less design ensures silent operation, making it an excellent choice for offices, retail spaces, meeting rooms, and other noise-sensitive locations.
Features
- 9 × Gigabit RJ45 ports and 1 × Gigabit SFP port for flexible network expansion
- 8 × PoE+ ports deliver power and data over a single Ethernet cable
- Supports IEEE 802.3af/at-compliant powered devices
- Up to 30W PoE output per port with a 63W total PoE budget
- Plug-and-play deployment with no configuration or software installation required
- QoS traffic prioritisation for smooth voice and video performance
- IGMP Snooping improves IPTV and multimedia traffic delivery
- Intelligent Power Management helps protect against PoE power overload
- Durable metal housing with desktop and wall-mount installation options
- Fanless design for silent and reliable operation
Kit Contents
- TL-SG1210P
- Power Adapter
- Installation Guide
Manuals & Datasheets
Technical
| HARDWARE FEATURES | |
|---|---|
| Interface | 8 PoE+ 10/100/1000Mbps RJ45 Ports 1 10/100/1000Mbps RJ45 Port 1 Gigabit SFP Slot |
| Network Media |
|
| Fan Quantity | Fanless |
| Physical Security Lock | Yes |
| Power Supply | External Power Adapter(Output: 53.5VDC / 1.31A) |
| Backup Bandwidth | 20Gbps |
| PoE Ports (RJ45) | Standard: 802.3at/802.3af compliant PoE Ports: Port1- Port 8 PoE Power Budget: 63W |
| Dimensions (W x D x H) | 209 x 126 x 26mm |
| Max. Power Consumption | 7.11 W (220/50Hz. no PD connected) 78.13 W (220/50Hz. with 63W PD connected) |
| Max. Heat Dissipation | 24.25 BTU/h (no PD connected) 266.42 BTU/h (with 63W PD connected) |
| PERFORMANCE | |
| Switching Capacity | 20Gbps |
| Packet Forwarding Rate | 14.88Mpps |
| MAC Address Table | 4K |
| Packet Buffer Memory | 4.1Mb |
| Jumbo Frame | 16KB |
| SOFTWARE FEATURES | |
| Advanced Features |
EEE802.3x Flow Control 802.1p/DSCP QoS IGMP Snooping |
| Transmission Method | Store-And-Forward |
| OTHER | |
| Certification | FCC, CE, RoHS |
| Package Content |
|
| Environment | Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing |
