The TP-Link TL-SF1016D is a reliable and cost-effective 16-port Fast Ethernet switch designed for home offices, small businesses, and workgroups that need to expand their wired network. Featuring 16 auto-negotiating 10/100Mbps RJ45 ports, it provides a simple way to connect computers, printers, IP cameras, NAS devices, and other network equipment while maintaining stable and efficient data transfer.
Designed for effortless deployment, the TL-SF1016D offers plug-and-play installation with no configuration required. Auto MDI/MDIX support automatically detects cable types, eliminating the need for crossover cables and simplifying network expansion. The switch incorporates IEEE 802.3x flow control to ensure reliable performance and minimise network congestion.
Combined with TP-Link's energy-efficient technology, the TL-SF1016D automatically adjusts power usage based on link status and cable length, helping to reduce energy consumption without compromising performance. Its compact, fan-less design allows for quiet operation in office and desktop environments, while flexible desktop or wall-mount installation options make it suitable for a wide range of networking applications.
Features
- 16 10/100Mbps Auto-Negotiation RJ45 ports, Supports Auto MDI / MDIX
- Green Ethernet technology saves power consumption
- IEEE 802.3x flow control provides reliable data transfer
- Plastic case, desktop or wall-mounting design
- Plug and play, no configuration required
Kit Contents
- 1x TL-SF1016D
- 1x Power Adapter
- Instruction Manual
Technical
| HARDWARE FEATURES | |
|---|---|
| Interface | 16 x 10/100 Mbps RJ45 Ports AUTO Negotiation/AUTO MDI/MDIX |
| Fan Quantity | Fanless |
| Physical Security Lock | No |
| Power Supply | External Power Adapter(Output: 9.0VDC / 0.6A) |
| Dimensions (W x D x H) | 7.9 x 5.6 x 1.6 in. (200 x 142 x 40 mm) |
| Max. Power Consumption | 3.23 W (220V/50Hz) |
| Max. Heat Dissipation | 11.01 BTU/h |
| PERFORMANCE | |
| MAC Address Table | 2K |
| SOFTWARE FEATURES | |
| Advanced Features | Green Technology, saving power up to 80% 802.3X Flow Control, Back Pressure |
| Transmission Method | Store-And-Forward |
| OTHER | |
| Certification | FCC, CE, RoHS |
| Package Content |
|
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment | Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing |
