The Omada TL‑SG108S‑M2 is an 8‑port 2.5G Multi‑Gigabit switch built to boost modern networks with up to 40 Gbps switching capacity. Its eight 2.5‑Gigabit ports provide fast, stable links for devices like 2.5G NAS units, WiFi 6/7 access points, gaming PCs, and 4K media systems.
Designed for simple upgrading, it supports 2.5G speeds over existing Cat5e cabling, avoiding the need to rewire. A fanless metal chassis, desktop or wall mounting, and plug‑and‑play setup make it suitable for homes, studios, and small offices.
With auto‑negotiation (100M/1G/2.5G), QoS, multicast optimisation, and loop prevention, the TL‑SG108S‑M2 ensures smooth, low‑latency performance for tasks like large file transfers, streaming, and gaming.
Features
- 8× 2.5-Gigabit ports unlock the highest performance of your Multi-Gig bandwidth and devices, and provide up to 40 Gbps of switching capacity.
- Provides super-fast connections to 2.5G NAS, 2.5G Server, gaming computer, 2.5G WiFi 6 AP, 4K video, and more.
- Built for LAN parties, home entertainment, small and home offices, and instant transfer for workstations.
- Instantly upgrade to 2.5 Gbps without the need to upgrade to Cat6 wiring, reducing wiring costs and hassle.
- Industry-leading fanless design ensures silent operation, ideal for any home or business.
- Allows for easy deployment without the need for a technician.
- Durable metal casing and desktop/wall-mounting design are well-suited for different environments.
Kit Contents
- 1x 8-Port 2.5G Multi-Gigabit Desktop Switch TL-SG108S-M2
- 1x Power Adapter
- 1x Installation Guide
- 4x Rubber Feet
Manuals & Datasheet
Technical
| General | |
|---|---|
| Standards and Protocols | IEEE 802.3u, 802.3ab, 802.3x, 802.1p, 802.3bz |
| Interface | 8× 100Mbps/1Gbps/2.5Gbps Ports, Auto-Negotiation, Auto-MDI/MDIX |
| Fan Quantity | Fanless |
| External Power Supply | External Power Adapter (Output: 12 VDC / 1.0 A) |
| LED | Power Link/Act Indicators |
| Dimensions (W x D x H) | 6.2 × 4.0 × 1.0 in (158 × 101 × 25.4 mm) |
| Max. Power Consumption | 8.87 W |
| Max. Heat Dissipation | 30.158 BTU/h |
| Performance | |
| Switching Capacity | 40 Gbps |
| Packet Forwarding Rate | 29.8 Mpps |
| MAC Address Table | 4 K |
| Jumbo Frame | 12 KB |
| Software Features | |
| Advanced Features | 802.3X Flow Control 802.1p/DSCP QoS IGMP Snooping |
| Transmission Method | Store and Forward |
| Others | |
| Certification | CE, FCC, RoHS |
| Package Content | 8-Port 2.5G Multi-Gigabit Desktop Switch TL-SG108S-M2 Power Adapter Installation Guide Rubber Feet |
| Environment | Operating Temperature: 0 to 40 °C (32 to 104 °F) Storage Temperature: -40 to 70 °C (-40 to 158 °F) Operating Humidity: 10 to 90 percent RH non-condensing Storage Humidity: 5 to 90 percent RH non-condensing |
