The TP-Link LS1210GP is a versatile Gigabit PoE+ switch designed for small business networks, IP surveillance systems, and wireless deployments. Featuring 9 Gigabit RJ45 ports and 1 Gigabit SFP uplink port, it delivers high-speed connectivity with a switching capacity of up to 20Gbps, making it ideal for demanding network environments. Equipped with 8 PoE+ ports supporting the IEEE 802.3af/at standards , the LS1210GP can provide both power and data over a single Ethernet cable to devices such as IP cameras, wireless access points, and IP phones. With a 61W total PoE power budget and up to 30W per PoE port , it offers a simple and cost-effective way to deploy powered network devices.
For surveillance installations, Extend Mode enables PoE transmission distances of up to 250 metres, allowing devices to be deployed further from the switch without additional infrastructure. The switch also features PoE Auto Recovery, which automatically reboots unresponsive PoE-powered devices to help maintain reliable operation and minimise downtime.
Features
- 9 x Gigabit RJ45 ports and 1 x Gigabit SFP uplink port for flexible network expansion
- 8 x PoE+ ports supporting IEEE 802.3af/at standards
- 61W total PoE budget with up to 30W output per PoE port
- Up to 20Gbps switching capacity for fast and reliable data transfer
- Extend Mode enables PoE transmission up to 250m for long-distance deployments
- PoE Auto Recovery automatically reboots unresponsive PoE devices
- Isolation Mode separates client traffic for enhanced network security
- Plug-and-play installation with no software or configuration required
- Fanless, silent operation ideal for offices and noise-sensitive environments
- Durable metal enclosure with desktop and wall-mount installation options
Kit Contents
- TL-SG1008P
- Power Adapter
- Installation Manual
Manuals & Datasheets
Technical
| HARDWARE FEATURES | |
|---|---|
| Interface | 9 x 10/100/1000 Mbps RJ45 Ports (Ports 1 - 8 supports PoE+ output) 1 x Gigabit SFP Port |
| Network Media |
|
| Fan Quantity | Fanless |
| Installation | Desktop Wall Mounting |
| Physical Security Lock | Yes |
| Power Supply | External Power Adapter(Output: 53.5VDC / 1.31A) |
| PoE Ports (RJ45) | Standard: 802.3at/802.3af compliant PoE Ports: Ports 1 - 8, up to 30 W PoE output per port PoE Power Budget: 61W |
| Dimensions (W x D x H) | 8.2 x 4.9 x 1.0in (209 x 126 x 26mm) |
| Max. Power Consumption | 7.3 W (220/50Hz. no PD connected) 76.96 W (220/50Hz. with 61 W PD connected) |
| Max. Heat Dissipation | 24.82 BTU/h (no PD connected) 261.66 BTU/h (with 61 W PD connected) |
| PERFORMANCE | |
| Switching Capacity | 20Gbps |
| Packet Forwarding Rate | 14.88Mpps |
| MAC Address Table | 4K |
| Jumbo Frame | 16KB |
| SOFTWARE FEATURES | |
| Advanced Features |
|
| Transmission Method | Store-And-Forward |
| OTHER | |
| Certification | FCC, CE, RoHS |
| Package Content |
|
| Environment | Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing |
