The VIGI InSight S445S is a 4MP ColorPro 2.0 turret network camera designed to deliver clear, detailed surveillance in both day and low-light conditions.
Its advanced AI-ISP technology, 1/1.79" sensor and large F1.0 aperture lens capture bright, full-colour images even in very low light. Intelligent IR and white-light illumination provide enhanced visibility after dark.
Intelligent Security
AI-powered human and vehicle classification helps distinguish important activity from other movement. Smart detection features include intrusion, line crossing, region entry and exit, loitering, and people and vehicle detection.
The camera also supports People & Vehicle Attributes Analytics, making it easier to search recorded footage using specific characteristics.
Clear Images in Any Conditions
With 120 dB True WDR, Smart IR and 3D DNR, the S445S helps produce clear, balanced footage in scenes with challenging lighting.
It supports 4MP resolution up to 2688 x 1520 and H.265+ video compression to help reduce bandwidth and storage requirements.
Flexible Installation
The built-in microphone and speaker provide two-way audio, while PoE support allows power and data to be delivered through a single network cable.
The camera supports microSD cards up to 512GB, ONVIF compatibility and VIGI VMS and VIGI Cloud VMS.
Designed for Outdoor Use
With an IP67 weatherproof rating, durable metal housing and an operating temperature range of -30°C to 60°C, the S445S is suitable for demanding indoor and outdoor environments.
It is ideal for applications such as commercial premises, warehouses, car parks, farms and other areas requiring reliable low-light surveillance.
Key Features
- AI-ISP Powered Ultra Low-Light Color Night Vision
- 4MP Super-High Definition
- People & Vehicle Attributes Analytics
- Human & Vehicle Classification
- Smart Detection
- Two-Way Audio
- Smart Video Enhancement Technology
- Flexible Alarm In/Out Devices Integration
- IP67 Weatherproof
- H.265+ Compression Technology
Kit Contents
- 1 x VIGI Network Camera
- 1 x Quick Start Guide
- Waterproof Cable Attachments
- Mounting Accessories
Manuals & Datasheet
| CAMERA | |
|---|---|
| Image Sensor | 1/1.79” Progressive Scan CMOS |
| Shutter Speed | 1/3 to 1/10000 s |
| Slow Shutter | Yes |
| Minimum Illumination | 0.0005 Lux; 0 Lux with IR/White light |
| Day/Night Mechanism | IR Cut Filter |
| Day/Night Switch | Unified/Scheduled/Auto |
| LENS | |
| Type | Fixed Focal Lens |
| Focal Length | 2.8 mm |
| Aperture | F1.0 |
| FOV |
|
| Lens Mount | M12 |
| DORI Distance |
|
| ANGLE ADJUSTMENT (MANUAL) | |
| Range | Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
| ILLUMINATOR | |
| Illuminator On/Off Control | Auto/Scheduled/Always on/Always off |
| Integrated Infrared-White LED |
|
| VIDEO | |
| Max. Resolution | 2688x1520 |
| Main Stream |
|
| Sub-Stream |
|
| Bit Rate Control | CBR, VBR |
| Video Compression | Main Stream: H.265+/H.265/H.264+/H.264 Sub-Stream: H.265/H.264 |
| H.264 Type | High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Video Bit Rate | Main Stream: 256 Kbps to 6 Mbps Sub-Stream: 64 Kbps to 1024 Kbps |
| IMAGE | |
| Image Settings |
|
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
| Wide Dynamic Range | 120dB |
| SNR | ≥52dB |
| Image Parameters Switch | Yes |
| Privacy Mask | Up to 4 Masks |
| ROI | 1 Region |
| OSD Setting | Yes |
| AUDIO | |
| Audio Communication | Two-Way Audio |
| Audio Input | Yes |
| Audio Output | Yes |
| Audio Compression | Yes |
| Audio Sampling Rate | 8KHz |
| Environment Noise Filtering | Yes |
| Audio Bit Rate | 64Kbps (G.711 alaw) |
| NETWORK | |
| Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP |
| ONVIF | Yes |
| API | Open Network Video Interface (Profile S/T/G) |
| Simultaneous Live View | 3 Main Streams & 3 Sub-Streams |
| Client | VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, VIGI Config Tool, VIGI PC Client |
| Web Browser |
|
| Cloud | Yes |
| Security | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication, 802.1X Authentication |
| ALARM AND EVENT MANAGEMENT | |
| Smart Event |
|
| Basic Event |
|
| Alarm Linkage |
|
| DEEP LEARNING FUNCTION | |
| People & Vehicle Analytics | Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier. |
| INTERFACES | |
| Network Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Alarm | 1 Alarm In, 1 Alarm Out |
| Reset Button | Yes |
| Power | DC Power Port |
| On-board Storage | Built-In Memory Card Slot, Support MicroSD Card, up to 512 GB |
| Built-in Microphone | Yes; Records Anything Going on within a 16.4ft (5m) Radius of the Camera |
| Built-in Speaker | Yes |
| GENERAL | |
| Environment | Operating Temperature: -30 ~ 60°C Storage Temperature: -40 ~ 60°C Operating Humidity: 95% or Less (Non-Condensing) Storage Humidity: 95% or Less (Non-Condensing) |
| Package Content |
|
| Material | Metal |
| Net Weight | 0.55 Kg |
| Power Supply |
PoE: 802.3at, Class 4, Max. 17.9 W |
| Protection | IP67 Weatherproof |
| Dimensions | Φ4.4 x 3.2 in (Φ111 x 81.4 mm) |
| Certification | CE, NTRA, VCCI, KC, IC, BSMI, FCC, IP67, ONVIF |
