The TP-Link EAP725-Wall is a compact Wi-Fi 6 wall-plate access point designed to deliver fast and reliable wireless connectivity directly to individual rooms. Ideal for hotels, offices, and multi-room deployments, it provides strong in-room coverage in a discreet, wall-mounted form factor.
Powered by Wi-Fi 6, it offers improved speeds, lower latency, and better performance when multiple devices are connected. Built-in Ethernet ports allow additional wired devices such as PCs, IP phones, or smart TVs to be connected easily without extra switches.
With Power over Ethernet support, installation is simple using a single cable for both power and data. Fully integrated with the Omada platform, the EAP725-Wall enables centralised management and monitoring, making it easy to deploy and manage across multiple rooms and sites.
Features
- BE3600 Wi-Fi 7 (2882Mbps on 5GHz + 688Mbps on 2.4GHz).
- 1 x 2.5G PoE input port + 1 x 2.5G pass-through port + 2 x Gigabit RJ45 downlink ports.
- 160MHz bandwidth enables many more simultaneous transmissions.
- MLO and Multi-RUs ensure the high performance of your network.
- Advanced Functions: Centralized management, Mesh, and Seamless Roaming.
Kit Contents
- EAP725-Wall
- Installation Guide
- Mounting Kits
Manuals & Datasheet
Technical
| Hardware Features | |
|---|---|
| Interface | Uplink: 1 x 2.5G Ethernet Port Downlink: 1 x 2.5G Ethernet Port + 2 x Gigabit Ethernet Ports (The 2.5G port supports PoE pass-through. The PoE pass-through feature requires 802.3at/bt input. If the power consumption of the AP's downstream device exceeds 7W, the AP needs an 802.3bt input.) |
| Physical Security Lock | No |
| Button | Reset LED |
| Power Supply | 802.3at/bt PoE |
| PoE Out | PoE Passthrough (Pins 1,2-; 3,6+) The PoE pass-through feature requires 802.3at/bt input. If the power consumption of the AP's downstream device exceeds 7W, the AP needs an 802.3bt input. |
| Max. Power Consumption | 802.3bt: 17W (PoE Out support 15.4W) 802.3at: 17W (PoE Out support 7W) |
| Dimensions (W x D x H) | 143 x 86 x 40mm (5.6 x 3.4 x 1.6in) |
| Antenna | 4 x Internal Antennas 2.4GHz: 2 x 4dBi 5GHz: 2 x 5dBi |
| Bluetooth | V5.2 |
| Mounting | Wall Mounting (Kits included) |
| Wireless Features | |
| Coverage | 50㎡(600ft²) |
| Concurrent Clients | 250+ |
| Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax/be |
| Frequency | 2.4 GHz, 5 GHz |
| Signal Rate | 5 GHz: Up to 4324Mbps 2.4 GHz: Up to 688Mbps |
| Wireless Functions |
|
| Wireless Security |
|
| Transmission Power | <22 dBm (2.4 GHz) <22 dBm (5 GHz, band 1 & band 2 & band 3 & band 4) |
| Management Features | |
| Omada App | Yes |
| Centralised Management | Omada Cloud-Based Controller Omada Hardware Controller (OC300, OC200) Omada Software Controller |
| Cloud Access | Yes, requires the use of an Omada controller |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging Local/Remote Syslog | System Log |
| SSH | Yes |
| Wed-based Management | HTTP/HTTPS |
| L3 Management | Yes |
| Multi-site Management | Yes |
| Management VLAN | Yes |
| Zero-Touch Provisioning | Yes, requires the use of Omada Cloud-Based Controller |
| Other | |
| Certification | FCC, RoHS |
| Package Content | EAP725-Wall Installation Guide Mounting Kits |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Environment | Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) Operating Humidity: 10% ~ 90% RH non-condensing Storage Humidity: 5% ~ 90% RH non-condensing |
