The TP-Link EAP650-Desktop is a compact Wi-Fi 6 access point designed to deliver fast, reliable wireless connectivity in small offices, meeting rooms, retail spaces, and home office environments. Its desktop form factor provides flexible placement without the need for ceiling or wall mounting.
Powered by Wi-Fi 6 technology, it delivers higher speeds, lower latency, and improved efficiency when multiple devices are connected. Features such as OFDMA and MU-MIMO help ensure smooth performance for everyday business applications, video conferencing, and cloud-based services.
With a compact design and simple deployment, the EAP650-Desktop is ideal for locations where traditional access point installation may not be practical. Fully integrated with the Omada platform, it supports centralised management and monitoring, making it easy to deploy and manage as part of a larger business network.
Features
- Blazing-Fast AX3000 Wi-Fi 6 Speeds: 2402 Mbps on 5GHz and 574 Mbps on 2.4 GHz totals 2976 Mbps Wi-Fi speeds
- Easy and Quick Installation: Plug-and-play on the desk or easy mounting on the wall
- Multiple Gigabit Ports: Connect multiple devices with 4 x Gigabit Ethernet Ports
- Convenient Deployment: Supports both 802.3bt PoE++ and DC (adapter included) for easy and quick deployment.
- Low Latency and Interference: 160 MHz bandwidth, OFDMA, MU-MIMO, and 1024-QAM ensure high performance for your network
- Advanced Functions: Omada Mesh, Seamless Roaming, Centralised Cloud Management
- More Connections and Wider Coverage: Supports 250+ concurrent connections and covers up to 1500 ft² (140 m²)
Kit Contents
- EAP650-Desktop
- Desktop/Wall Mounting Kit
- Installation Guide
- Power Adapter
Manuals & Datasheet
Technical
| Hardware Features | |
|---|---|
| Interface | 4 x 1 Gbps Ethernet Ports + 1 x FXS Port (One Ethernet port supports PoE Out: 802.3at/af output at 802.3bt input, 802.3af class 2 output at 802.3at input) |
| Button | Reset LED |
| Power Supply | 802.3 af/at/bt PoE or 12 V/1.5 A DC *PoE Out requires 802.3at/bt PoE power supply |
| Max. Power Consumption |
|
| Weight | 0.5kg (excluding mounting base) |
| Dimensions (W x D x H) | 6.9 x 5.5 x 1.3in (175 x 140 x 33mm) |
| Antenna | Internal Omni
|
| Range | 1500ft2 (140m2) |
| Mounting | Desktop / Wall Mounting (Kits included) |
| Wireless Features | |
| Concurrent Clients | 250+ |
| Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax |
| Frequency | 2.4 GHz and 5 GHz |
| Signal Rate | 5GHz: Up to 2402Mbps 2.4GHz: Up to 574Mbps |
| Wireless Functions |
|
| Wireless Security |
|
| Transmission Power |
|
| Management Features | |
| Omada App | Yes |
| Centralised Management | Omada Cloud-Based Controller Omada Hardware Controller Omada Software Controller |
| Cloud Access | Yes, Requires the use of an Omada Controller |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging Local/Remote Syslog | System Log |
| SSH | Yes |
| Web-based Management | HTTP/HTTPS |
| Zero-Touch Provisioning | Yes, requires the use of Omada Cloud-Based Controller |
| Other | |
| Certification | CE, FCC, RoHS |
| Package Content | EAP650-Desktop Desktop/Wall Mounting Kit Installation Guide Power Adapter |
| Environment | Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) Operating Humidity: 10% ~ 90% RH non-condensing Storage Humidity: 5% ~ 90% RH non-condensing |
