The TP-Link EAP625GP-Wall is a compact Wi-Fi 6 wall-plate access point designed to deliver fast, reliable in-room wireless coverage with added wired flexibility. Ideal for hotels, offices, and shared living spaces, it combines high-speed Wi-Fi with built-in switching in a discreet wall-mounted design.
Powered by Wi-Fi 6, it offers improved speeds, lower latency, and better performance when multiple devices are connected. Integrated Ethernet ports allow you to connect wired devices such as PCs, IP phones, or smart TVs, while PoE passthrough enables power to be forwarded to another device.
With Power over Ethernet support, installation is simple using a single cable for both power and data. Fully integrated with the Omada platform, the EAP625GP-Wall enables centralised management and monitoring, making it easy to deploy and manage across multiple rooms and sites.
Features
- Seamless 1.8Gbps WiFi 6 Speeds: 1201Mbps on 5GHz & 574Mbps on 2.4GHz
- Multiple Ports: 1 x GPON port for high-speed, ultra-range access and 2 x Gigabit RJ45 ports (one supporting 802.3af PoE out) for flexible deployment
- One Fibre for Multiple Services: Wired, Wireless, Voice, VoIP, Data, and HD Video Services
- VoIP Calls: Support multiple VolP accounts and various call features, exceeding traditional landlines
- Easy Use: One-Click Pairing and Automatic Adoption
- Advanced Functions: Unified Management for OLT and Omada Devices, Omada Mesh, and 802.11k/v/r Seamless Roaming
Kit Contents
- EAP625GP-Wall
- Wall Mounting Kit
- Installation Guide
Manuals & Datasheet
Technical
| Hardware Features | |
|---|---|
| Interface | 1 x GPON Port 1 x FXS Port 2 x Gigabit RJ45 Ports (One supporting 802.3af PoE Out) |
| GPON Interface |
|
| Button | Reset LED |
| Power Supply | 100-240V ~ 50/60Hz, 0.5A |
| Max. Power Consumption | 30.5W (PoE out full load 15W) |
| Weight | 350g |
| Dimensions (W x D x H) | 5.6 x 3.4 x 1.8in (143 x 86 x 44.6mm) |
| Antenna | Internal Omni 2.4GHz: 2 x 4dBi 5GHz: 2 x 6.5dBi |
| Mounting | Wall Mounting (Kits Included) |
| Wireless Features | |
| Concurrent Clients | 120+ |
| Coverage | 600 ft² (50㎡) |
| Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax |
| Frequency | 2.4 GHz, 5 GHz |
| Signal Rate | 5 GHz: Up to 1201Mbps 2.4 GHz: Up to 574Mbps |
| Wireless Functions |
|
| Wireless Security |
|
| Transmission Power |
|
| Management Features | |
| Omada App | Yes |
| Centralised Management | Omada Cloud-Based Controller Omada Hardware Controller Omada Software Controller |
| Cloud Access | Yes, requires the use of an Omada controller |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1, v2c, v3 |
| System Logging Local/Remote Syslog | System Log |
| SSH | Yes |
| Wed-based Management | Yes |
| Zero-Touch Provisioning | Yes, requires the use of Omada Cloud-Based Controller |
| Other | |
| Certification | FCC, CE, RoHS, IC |
| Package Content | EAP625GP-Wall Installation Guide Wall Mounting Kit |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Environment | Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) Operating Humidity: 10% ~ 90% RH non-condensing Storage Humidity: 5% ~ 90% RH non-condensing |
