Omada 20-Port Gigabit Easy Managed Switch with 16-Port PoE+

The Omada ES220GMP is an Easy Smart Gigabit PoE+ switch designed for small business and professional networks that need simple management and reliable PoE power in a compact form factor. Featuring 16 Gigabit PoE+ ports and 4 Gigabit uplink ports, it provides flexible connectivity for access points, IP cameras, VoIP phones, and other powered network devices.

Built for straightforward deployment, the ES220GMP supports essential smart switching features including VLANs, QoS, loop prevention, and IGMP snooping, helping to maintain stable traffic flow for voice, video, and data applications. Intuitive web‑based management allows quick configuration and monitoring without the complexity of fully managed switches.

As part of the Omada ecosystem, the ES220GMP offers consistent visibility and simplified operation within Omada‑based network environments. Its fanless metal chassis ensures silent, dependable performance, making it well suited for offices, retail spaces, classrooms, and hospitality environments where reliable PoE switching and ease of use are key.


Features

  • 16× Gigabit 802.3af/at-compliant PoE+ RJ45 ports
  • 2× Gigabit RJ45 port, 2× Gigabit SFP port
  • Supports plug-and-play for instant connectivity and simple configuration for additional features
  • Centralised Cloud Management via the web or the Omada app
  • Up to 250m PoE, QoS, PoE Auto Recovery, and Port Isolation for reliable surveillance networking
  • Automatic Loop Prevention, VLAN, and IGMP Snooping
  • Durable metal casing and rack-mountable design


Kit Contents

  • ES220GMP Switch
  • Power Cord
  • Mounting Brackets
  • Rubber Feet
  • Screws
  • Installation Guide


Technical


CategorySpecification
Hardware Features
  • Interfaces: 16 × 10/100/1000 Mbps PoE+ RJ45 ports supporting 802.3af and 802.3at, 2 × 10/100/1000 Mbps RJ45 ports, 2 × Gigabit SFP slots with auto negotiation and auto MDI and MDIX
  • Fan Quantity: 2
  • Installation: Rack mountable
  • Physical Security Lock: Yes
  • Power Supply: 100–240 V AC, 50/60 Hz
  • PoE: 16 PoE ports, 802.3af and 802.3at compliant, 250 W total PoE budget, up to 30 W per port, fast PoE and perpetual PoE, PoE auto recovery, support for extended PoE transmission distance
  • Dimensions (W × D × H): 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm)
  • Surge Protection: ±6 kV
Performance
  • Switching Capacity: 40 Gbps
  • Packet Forwarding Rate: 29.76 Mpps
  • MAC Address Table: 8 K
  • Packet Buffer Memory: 4 Mbit
  • Jumbo Frame: 15 KB
Quality of Service
  • Port based, 802.1p and DSCP QoS
  • 8 priority queues
  • Scheduling mode: WRR
  • Queue weight configuration
  • Port based bandwidth control
  • Storm control with kbps and pps modes for broadcast, multicast and unknown unicast traffic
L2 Features
  • Static link aggregation
  • Loop prevention and loopback detection
  • 802.3x flow control
  • Port mirroring with one to one and many to one modes and ingress, egress or both directions
  • Port statistics including traffic and mirror status
  • LLDP support
L2 Multicast
  • IGMP snooping
  • IGMP v1, v2 and v3 snooping
  • Fast leave support
VLAN
  • MTU VLAN
  • Port based VLAN
  • 802.1Q tagged VLAN
  • Up to 32 VLAN groups with 4K VLAN IDs
Transmission MethodStore and forward
Management
  • Omada Cloud, Hardware and Software Controller support
  • Zero Touch Provisioning via Omada Cloud Controller
  • Web based GUI
  • DHCP client
  • Cable diagnostics
  • Automatic device discovery, batch configuration and batch firmware upgrade
  • Unified configuration
Others
  • Certifications: FCC, CE, RoHS
  • Package contents: ES220GMP switch, power cord, mounting brackets, rubber feet, screws and installation guide
  • Operating temperature: -5 to 50 °C
  • Storage temperature: -40 to 70 °C
  • Operating humidity: 10–90% RH non condensing
  • Storage humidity: 5–90% RH non condensing

Omada 20-Port Gigabit Easy Managed Switch with 16-Port PoE+

  • Brand: TP-Link
  • Product Code: ES220GMP
  • Availability:  In Stock
