The TP-Link MC110CS is a Gigabit media converter designed to extend network connections by converting standard Ethernet into fibre optic links. It's ideal for surveillance systems, campus networks, and long-distance connections where copper cabling isn't practical.
Supporting Gigabit speeds, the MC110CS ensures stable, high-speed data transmission, helping maintain reliable performance over extended distances. It uses a fixed fibre interface, making it a straightforward solution for single-mode fibre deployments.
With a plug and play design, the MC110CS requires no configuration, allowing for quick and easy installation. Its compact and durable build makes it suitable for a wide range of environments where dependable fibre connectivity is needed.
Features
- Complies with 802.3u 10/100Base-TX, 100Base-FX standards
- Auto-negotiation of Half-Duplex / Full-Duplex transfer mode
- Extends fiber distance up to 20km
Kit Contents
- 1 x MC110CS
- 1 x Power Adapter
- 1 x Installation Guide
Manuals & Datasheet
Technical
| Media Converter & Module | |
|---|---|
| Standards & Protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Interface | 2 x 100M SC/UPC ports 1 x 10/100M RJ45 port (Auto MDI/MDIX) |
| Network Media 10BASE-T | UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
| Network Media 100BASE-T | UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
| Network Media 100BASE-FX | Single-mode Fibre |
| Dimensions (W x D x H) | 3.7 x 2.9 x 1.1in (94.5 x 73.0 x 27.0mm) |
| Power Supply | External Power Supply |
| Max. Power Consumption | 2.4V |
| LED | PWR, Link / Act |
| Safety & Emission | FCC, CE, RoHS |
| Package Content |
|
| Environment | Operating Temperature: 0°C ~ 50°C (32°F ~ 122°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing |
