1.0_10G_L3_PoE_Switch_01_thumb_20231110073609h-500x500.jpg "Omada 48-PortGigabit Stackable L3 Managed PoE+ Switch with 6 10GE SFP+ Slots")
Click Image for Gallery
1.0_10G_L3_PoE_Switch_05_normal_20231110073819q-500x500.jpg "Omada 48-PortGigabit Stackable L3 Managed PoE+ Switch with 6 10GE SFP+ Slots")
1.0_10G_L3_PoE_Switch_04_normal_20231110073800r-500x500.jpg "Omada 48-PortGigabit Stackable L3 Managed PoE+ Switch with 6 10GE SFP+ Slots")
1.0_10G_L3_PoE_Switch_03_normal_20231110073654w-500x500.jpg "Omada 48-PortGigabit Stackable L3 Managed PoE+ Switch with 6 10GE SFP+ Slots")
1.0_10G_L3_PoE_Switch_02_thumb_20231110073633x-500x500.jpg "Omada 48-PortGigabit Stackable L3 Managed PoE+ Switch with 6 10GE SFP+ Slots")
The Omada SG6654X is a high‑performance Layer 3 managed switch designed to meet convergence‑layer networking demands for SMB, enterprise, and ISP environments. It features 48 Gigabit RJ45 ports, 6× 10 Gbps SFP+ slots, physical stacking of up to 4 units, and internal fixed redundant power supplies, delivering up to 216 Gbps switching capacity per unit and 864 Gbps when stacked. The switch supports advanced Layer 3 routing protocols including Static Routing, RIP, OSPF, ECMP, VRRP, DHCP Server and Relay, and PIM‑DM for efficient multicast routing, while ERPS ensures rapid protection and recovery in ring topologies. Comprehensive security features such as IPv4/IPv6 ACLs, Dynamic ARP Inspection, IEEE 802.1X, MAB, Port Security, and SSH protect against network threats. Fully integrated with the Omada SDN platform, it enables centralized cloud management, Zero‑Touch Provisioning, and flexible local management via web GUI or CLI, with secure SSL/SSH, SNMP (v1/v2c/v3), and RMON support for monitoring and alerts.
Features
- 48× Gigabit RJ45 PoE+ ports
- 6× 10 Gbps SFP+ slots
- Up to 1440 W total PoE budget
- Physical Stacking for built-in redundancy and performance
- L3 features: RIP, OSPF, ECMP, VRRP, PIM-DM, DHCP Server/Relay
- Security Strategies: ACL, Port Security, DoS Defend, 802.1X
- Highly Available with two field-replaceable power supplies, VRRP, and ERPS
- Centralised cloud management via the Omada SDN controller
- Standalone management via web, CLI, SNMP, and RMON
Kit Contents
- SG6654XHP Switch
- Power Cord
- RJ45 Console Cable
- Quick Installation Guide
- Rackmount Kit
- Rubber Feet
Manuals & Datasheet
Technical
| Hardware features | |
|---|---|
| Interface | 48 × 10/100/1000 Mbps PoE+ RJ45 ports 6 × 10G SFP+ slots 2 × USB 2.0 ports 1 × RJ45 console port 1 × USB Type‑C console port 1 × RJ45 management port |
| Fan quantity | Four field‑replaceable and hot‑swappable fans |
| Power supply | Two field‑replaceable and hot‑swappable power supply modules 100–240 V AC, 50/60 Hz Ships with one PSM900‑AC module by default |
| PoE ports (RJ45) | Standard: IEEE 802.3af / 802.3at compliant PoE+ ports: 48 ports, up to 30 W per port Total PoE power budget: up to 1440 W |
| Dimensions (W × D × H) | 440 × 420 × 44 mm / 17.3 × 16.5 × 1.7 in |
| Mounting | Rack mountable |
| Max power consumption | 67.24 W (110 V / 60 Hz, no powered devices connected) 1767.7 W (110 V / 60 Hz, 1440 W PoE load with two PSM900‑AC modules) |
| Max heat dissipation | 229.29 BTU/hr (110 V / 60 Hz, no powered devices connected) 6027.86 BTU/hr (110 V / 60 Hz, 1440 W PoE load with two PSM900‑AC modules) |
| Performance | |
| Switching capacity | 216 Gbps per unit |
| Stacking | Stacking number: 8 Stacking ports: 10G SFP+ (all uplink ports can be used) Stack bandwidth: 20 Gbps per port (full‑duplex) |
| Packet forwarding rate | 160.7 Mpps |
| MAC address table | 32 K |
| Packet buffer memory | 3 MB |
| Jumbo frame | 9 KB |
| Software features | |
| Quality of service | Class of service with 8 priority queues Port priority, IEEE 802.1p priority, DSCP priority Minimum bandwidth per queue Scheduling modes: SP, WRR, SP + WRR Rate limiting and storm control QoS remarking (802.1p, DSCP) |
| L3 features | IP interfaces: IPv4 (256), IPv6 (256) Static routing: IPv4 (1024), IPv6 (512) RIP v1/v2, OSPF v2/v3 VRRP v2/v3 (64 groups) ECMP (256 entries, 32 next hops) Static ARP (512), dynamic ARP (7680) DHCP server and relay |
| L2 and L2+ features | Link aggregation Spanning tree protocol Port‑based and VLAN‑based loopback detection 802.3x flow control IGMP and MLD snooping ERPS, RSPAN PIM‑DM (IPv4) |
| VLAN | 802.1Q VLAN (up to 4K VLAN groups) MAC VLAN, multicast VLAN, management VLAN QinQ, GVRP, protocol VLAN Voice VLAN, private VLAN |
| Security | Port isolation and CPU protection ARP inspection and DHCP snooping IPv4 and IPv6 source guard 802.1X authentication (port and MAC based) RADIUS and TACACS+ HTTPS (TLS 1.2) and SSHv2 IP, port and MAC based access control |
| Management features | |
| Omada app | Yes (requires Omada controller) |
| Centralised management | Omada cloud‑based controller Omada hardware controller Omada software controller |
| Zero‑touch provisioning | Yes (via Omada cloud‑based controller) |
| Management tools | Web‑based GUI CLI (console and telnet) SNMP v1 / v2c / v3, RMON LLDP / LLDP‑MED Dual image and dual configuration Cable diagnostics, system logs, SNTP, EEE |
| Others | |
| Package contents | SG6654XHP switch Power cord RJ45 console cable Quick installation guide Rackmount kit Rubber feet |
| System requirements | Windows, macOS, NetWare, UNIX or Linux |
| Environment | Operating temperature: 0°C to 45°C / 32°F to 113°F Storage temperature: -40°C to 70°C / -40°F to 158°F Operating humidity: 10% to 90% RH (non‑condensing) Storage humidity: 5% to 90% RH (non‑condensing) |
