The Omada ER7212PC is an all‑in‑one enterprise gateway designed to simplify network deployment for small and medium business environments. Combining a VPN router, PoE switch, and Omada controller in a single device, it reduces hardware complexity while delivering reliable performance, centralised management, and flexible power delivery.
Equipped with multiple Gigabit Ethernet ports, including integrated PoE+ support, the ER7212PC can directly power access points, IP cameras, and VoIP phones without the need for a separate PoE switch. Advanced routing, load balancing, and comprehensive VPN capabilities ensure secure and stable connectivity for both on‑site and remote users.
With a built‑in Omada controller, the ER7212PC enables full centralised management of Omada access points and switches without requiring external hardware or software. Cloud‑based access, unified configuration, and real‑time monitoring make it an ideal solution for offices, retail locations, hospitality, and branch deployments where simplicity, security, and space‑saving design are essential.
Features
- Integrates router, PoE+ output, and Omada centralised management ability altogether.
- Dual-Core CPU with 1GB DDR3 memory provides stellar performance for up to 12× Gigabit ports.
- Equipped with 2× Gigabit SFP WAN/LAN ports, 1× Gigabit RJ45 WAN port, and 1× Gigabit RJ45 WAN/LAN port.
- 8× 802.3at/af-compliant PoE+ RJ45 LAN ports yield a total power supply of 110W.
- Cloud access and the Omada app offer convenience and easy management.
- Supports IPsec VPN, OpenVPN, and L2TP/PPTP VPN connections.
- Fan-less and compact design for desktop and wall mounting.
Kit Contents
- ER7212PC Switch
- Power Adapter
- Power Cord
- Installation Guide
Manuals & Datasheet
Technical
| Category | Specification |
|---|---|
| Security |
|
| Hardware Features |
|
| Performance |
|
| Basic Functions |
|
| Advanced Features |
|
| VPN |
|
| Authentication |
|
| Management |
|
| Others |
|
