Aqara Single Switch Module T1 (No Neutral)

Small, but powerful single channel relay controller

The Aqara Single Switch Module T1 (No Neutral) is based on the Zigbee 3.0 wireless communication protocol. It can control the on/off status of lights. With the Aqara Hub, it can realize functions such as app remote control and timing control. It can work with other Aqara smart devices to realise more smart scenes.

Features:

  • No Neutral Wire Required: Even if your wall box doesn’t have a neutral wire, the Aqara Single Switch Module T1 can be installed and used.
  • Zigbee 3.0 Protocol: Enjoy the benefits of the fastest, most stable, and energy-efficient smart home technology.
  • Compact Size: Fits almost any wall box and can be connected to your existing wall switch or outlet.
  • 2-Way Switch Support: Can be connected to your existing 2-way switches and make them smart.
  • Power Off Memory: You will be able to configure if you need the lights to turn on automatically after a power outage.
  • Advanced Protection: With overheat protection, you can be sure your home is safe and secure.
  • Timers and Remote Control: Schedule the usage of your electric appliances, check the status, and control them remotely.
  • All-Round Compatibility: Supports most popular voice assistants and ecosystems.

Specifications:

  • Product Model: SSM-U02
  • Product Dimensions: 42.9×40×21.4 mm
  • Product Color: White
  • Net Weight (kg): 0.04
  • Gross Weight (kg): 0.05
  • Input Power: 100-250VAC,50/60Hz, μ
  • Input Current: MAX 5A (resistive load)
  • Rated Load: Min 3W, Max 1250W (resistive load), μ This product is only suitable for non-remote-control lights above 3W (typical value)
  • Wireless Connection: Zigbee 3.0
  • Wireless Standard: IEEE 802.15.4
  • Wireless Frequency: 2.4 GHz (2400~2483.5MHz)
  • Receiver Sensitivity: -98 dBm
  • Effective Communication Distance: 30m (indoors)
  • Operating Temperature: 0°C~ 35°C
  • Operating Humidity: 5% ~ 95% RH, non-condensing
  • Storage Temperature: -10°C~ 50°C
Details
Product TypeAqara Controller
Attributes

Product Model: SSM-U02

Product Dimensions: 42.9×40×21.4 mm

Product Color: White

Net Weight (kg): 0.04

Gross Weight (kg): 0.05

Input Power: 100-250VAC,50/60Hz, μ

Input Current: MAX 5A (resistive load)

Rated Load: Min 3W, Max 1250W (resistive load), μ This product is only suitable for non-remote-control lights above 3W (typical value)

Wireless Connection: Zigbee 3.0

Wireless Standard: IEEE 802.15.4

Wireless Frequency: 2.4 GHz (2400~2483.5MHz)

Receiver Sensitivity: -98 dBm

Effective Communication Distance: 30m (indoors)

Operating Temperature: 0°C~ 35°C

Operating Humidity: 5% ~ 95% RH, non-condensing

Storage Temperature: -10°C~ 50°C

Aqara Single Switch Module T1 (No Neutral)

  • Brand: Aqara
  • Product Code: SSM-U02
  • Availability:  In Stock
